Product Overview
In order to easily slice and lift the soil the 16 disc blades on this tractor disc harrow are spaced out by 7-1/2 in. The discs measure 16 inches in diameter, are 3 mm thick and all have a notched perimeter to better dig up and rotate the soil. This 5 ft. disc harrow provides a cutting width of 60 inches. It can be used with a tractor that has a horsepower of 25 to 45 HP. The construction is held together by cast iron bearings and 1 inch axles. Due to this smaller size, this 5 ft. disc harrow also matches quick hitch compatibility.
Specifications
- 5 Ft. Disc Harrow
- Number of disc blades: 16
- Disc blade diameter: 16 in. Diameter
- Disc blade thickness: 3 mm
- Disc blade spacing: 7-1/2 in.
- Axle Locknut size is 24M with Nylon Insert
- Cutting width: 60 in.
- Hitch: Category 1
- Tractor HP compatibility: 25 – 45 HP
- Bearing construction: Cast iron
- Axles: 1 in.
- Weight: 556 lbs
- Quick hitch compatible
- Use ASC 134732 – Nylon Locknut on the disc axle
