Product Overview
Specifications
- 2-5/8″ Round Center Hole
- 4 hole 3/8″ bolt hole size on a 3-5/8″ bolt pattern
- Hub to fit the following Coulters: 109076 – 20″ Fluted, 25921 – 20″ Flat, 25913 – 17″ Fluted, 30821 – 14″ Flat Coulter, 31050 – 14″ Wavy
- Replacement 28795 – Coulter Hub to fit KMC Digger Shaker Inverter
- Replacement 29353 – Snap Ring KMC (2 required)
- Replacement 17854 – 205 RRAN Bearing (2 required)
- Replacement 14555 – 3/4″ Set Collar (1 required)
- Replacement Axle Bolt13206 – Hex Head Bolt 3/4″ x 6″ (Grade 2) – (1 bolt required)
- Replacement Axle Nut13109 – 3/4″ Finished Hex Nut N.C. – (1 nut required)
- Replacement Axle Washers13089 – Flat Washer – (2 flat washers required)
- Replacement Lock Washer13099 – Lock Washer – (1 lock washer required)
- Replacement 28848 – Reinforcement Ring for Coulter Hub
- Replacement 29721 – Spacer to fit KMC (fits between the 2 bearings)
